OGM-1 granulator, 5, Kharkiv region.

TECHNICAL CHARACTERISTICS
INDUSTRIALGRANULATOR for OGM pellets 1.5
Parameter
Description
Full name Industrial granulator for pellets OGM 1.5
Quantity, pcs 1
Quality requirements, including warranty period Warranty period 12 months or 1000 hours of operation
Main engine power 75 kW 380V
Productivity up to 1000 kg/hour for sawdust
The diameter of the granules is 6-8 mm.
Total power 78.7 kW, 380V
Typereductor granulator type with ring matrix
2-stage press reducer type(//tractor-service.com)
The diameter of the matrix is 630 mm.
The number of revolutions of the matrix is 140 rpm
The diameter of the dispenser screw is up to 200 mm.
Power of the dispenser drive 1.5 kW 380V
The diameter of the mixer screw is up to 270 mm.
Mixer drive power 2.2kW 380V
The number of press-rolls is 2 pcs. 170
Диаметр пресс-роликов 190мм
Number of cutting knives 1 pc. 172
Требования к фракции сырья для гранулятора до 5х5 мм
Requirements for the moisture content of raw materials for granulation From 8 to 15%, depending on the initial raw materials
Dimensions 2.1x1.1x1.9 m
Weight 2100kg
