New 19 year Disc harrow BPD 3200×2 trailed disc 560mm- 24 units, Kherson region.

Disk harrow BPD 3200×2 disc 560 mm - 24 pieces Trailed two-row harrowdisc harrow BPD-3.2×2 is intended for resource-saving pre-sowing and main tillage to a depth of 8 to 15 cm for grain, technical and fodder crops, weed destruction and grinding of crop residues after harvesting crops, rejuvenation of meadows and pastures, as well as grinding, leveling and compaction of soil.

It can be used in all agro-climatic zones, on all types of soil, except stony and weedy ones.

Technical characteristics
Productivity for 1 hour of the main time (ha/h) up to 3.2
Working speed (km/h) up to 10
Width of capture, m 3.2±0.12
Constructive mass of the machine, kg 1842
Processing depth, cm up to 15
Overall dimensions (in working position), mm
Length 5265±160
Width 3366±100
Height 1150±35
Disc diameter, mm 560
Number of working bodies, pcs. 24
skating rink 1
Angle of attack of discs, degrees. 0° - 30°
Distance, mm
between disks in a row 250
between rows of discs 950
Service life, 8 years
(//tractor-service.com)
Indicators of the quality of soil treatment
The ridge of the soil surface, no more (see) 3
Crumbling soil, not less (the size of lumps not more than 25 mm.) (%) 90
Grinding of harvest residues (%) 80
Plant and harvest residue closure (%) 90

Aggregability - 90 hp: DT-75, MTZ 892.2
Attention!
BDP disc harrow 3200×2
The processing quality is ensured on soils with specific resistance up to 0.09 MPa (0.9 kg/cm2), hardness up to 3.0 MPa (30 kg/cm2) and ultimate humidity up to 25%.
Harrows BDP disk harrow 3200×2
prevent soil drying;
destroy weeds;
increase the microbiological activity of the soil;
perform no-till soil cultivation to a smaller depth compared to plows;
reduce the amount of tillage, save time and money, unlike traditional technology;
allow soil processing at high humidity.
Advantages
Processing depth up to 150mm.
Clogging is excluded when working on wet and clogged soils.
Winding plant residues on working bodies is excluded. Disks are located on individual racks.
Increased durability of the bearing unit
Effective grinding of plant residues.
Durable and resistant to external influences (POWDER PAINT)
