Tractor Kioti DS4510, new, Korea, from exhibitions, 2013, Vinnytsia region.

ENGINE
Model 4A220LWE
Working volume (cm3) 2197
Engine power (kW / hp) 33.6 / 45
Nominal rotation frequency (rpm) 2600
Engine type four-stroke
Number of cylinders 4
Type of fuel diesel
The type of cooling system is water.
The type of arrangement of the cylinders is vertical.
Direct fuel injection type
The type of air filter is dry
"Cold start" system yes
TRANSMISSION
Gearbox type unsynchronized mechanical (4 forward / 4 reverse)*2
The type of clutch is single-disc.
GENERAL TECHNICAL PARAMETERS
Wheel formula 4 x 4
Structural weight (kg) 1,600
Front counterweights (kg) no
Rear counterweights (kg) no
Maximum speed (km/h) 1.69 ~ 23.38
Maximum reverse speed (km/h) 1.57 ~ 21.57
Length including rear suspension (mm) 3169
Width (mm) 1574
Height (mm) 2521
Wheelbase (mm) 1850
Front wheel track (mm) 1246
Rear wheel track (mm) 1,170 ~1,480
Agricultural clearance (mm) 348
Nominal voltage of the electrical system (in) 12V
RUNNING SYSTEM
Drive type is direct
Rear differential lock yes
The size of the fronttires 8.00-16(//tractor-service.com)
The size of the rear tires is 12.4-24
Power steering yes
Multi-disc working brake in an oil bath
Parking brake with a mechanical drive
HYDRAULIC SYSTEM
Number of hydraulic pumps 1
The rear suspension is three-point.
Number of hydraulic valves 1 pair
Hydraulic outlet under the trailer yes
Additional distributor no
Maximum lifting force (kN) 1 100
Diameter of the upper suspension point (mm) 19.3
Diameter of the lower suspension point (mm) 22.4
REAR PTO SHAFT
Type dependent
Standard size of a shaft with splines (six teeth Ø 35 (mm)
Rotational frequency (rpm) 540
FILLING VOLUMES
Fuel tank (l) 42
Radiator (l) 8.9
Engine oil sump (l) 8
Gearbox (l) 40
Front axle (l) 7.5
KIT
The engine hours counter is yes
Spring-loaded seat yes
Compressor no
Rear-view mirrors yes
Front wings no
Mass switch no
Socket for the trailer yes
Accidental launch protection yes
Safety arc yes
Cabin no
No tape recorder
No air conditioner
