Producer: India
Country of assembly: India
Construction weight, without hinged equipment, kg: 1055 kg
Dimensions: Length 2705 | Width 1058 | The height of the cabin at the top point is 2153
Ground clearance, mm: 225
The size of the rear wheels: 8.3" - 20"
The size of the front wheels: 6" - 12"
Front track, mm. 894
Rear track, mm. 825
Rotation speed of the rear PTO, rpm. 540 / 1000
Type of gearbox: Mechanical
The number of gears: (3 + 1) * 2, with a lower gear
Differential lock: Mechanical, foot
Wheel formula: 4WD all-wheel drive
Power steering (GUR): Fully hydraulic steering gear with a separate hydraulic circuit
Type of braking system: Disc brake, separate for each
wheels
Type of clutch: single-disc one-stage, dry, with constant engagement
(//tractor-service.com)
Number of additional hydraulic outlets: 1 pair
System of light: Far and near light Turn signals | Side lights | Stop signal | Illumination of the rear suspension
Sound signal: Klaxon
Dashboard: Voltmeter | Coolant temperature sensor | Oil pressure sensor | Hour meter
Diesel Engine Mitsubishi MVS3L2-JC
Engine type: Diesel
Made in Japan
Power: 24 hp.
Number of cylinders: 3
Number of revolutions, rpm: 2700
Piston stroke, mm: 105
Cylinder diameter, mm: 76
Lubricant type:
Oil pump
Type of power take-off shaft: On the clutch basket
Starting system: Electrostarter
Cooling system: Water cooling
