Threader with spring stand LDVP -3m, Kirovohradska region.

Trailed disc machine Harrow peeler LDVP-3.LDVP peeler 3.
Technical characteristics.
Name of LDVP - 3.0 LDVP - 3.5 LDVP - 4.0 LDVP - 4.5 LDVP - 6.0 LDVP - 7.0 LDVP - 8.0
Trailer type
Working speed 10-14 km/h
The depth of soil treatment is 5 - 15 cm.
Height 800 ± 20 mm.
Long with roller 2180 ± 30 mm.
Width 2700 mm. 3000 mm. 3500 mm. 4000 mm. 4500 mm. 6020 mm. 7020 mm. 8020 mm.
Productivity 3.0 Ha/h. 3.2 Ha/h. 3.8 Ha/h. 4.5 ha/h. 5.3 Ha/h. 6.4 Ha/h. 7.5 Ha/h. 8.7 Ha/h.(//tractor-service.com)
Tractor power - L.S. 80÷90 90÷100 110÷130 130÷150 150÷160 180÷200 210÷230 240÷260
Transport speed, no more than 20 km/h.
Ground clearance, not less than 300 mm,
Number of working bodies 20 racks 22 racks 26 racks 30 racks 34 racks 46 racks 54 racks 62 racks
The distance between adjacent working bodies is 270 mm.
Disc inclination angle 10.5°
Angle of attack 19°
The diameter of the disc is 560 mm.
Number of rinks 1 2 4
Weight kg. 1800 ± 20 2000 ± 20 2300 ± 20 2600 ± 20 3000 ± 20 5000 ± 20 5500 ± 20 6200 ± 20
High-quality aggregate Luschylnyk.
