Zavodskaya Borona BDF-1.8-2.1-2, 4-2.8 models of disc harrows in Ukraine, Cherkasy region.

Zavodskaya BoronaBDF-1.8-2.1-2,4-2.8 models of disc harrows in Ukraine! The harrow is produced bothmounted BDF (working width from 1.8 to 3.1 meters) and trailed BDFP (working width from 2.4 to 7.0 meters). The harrow is intended for continuous and pre-sowing soil processing of various mechanical composition for technical, grain and fodder crops and with crushing and embedding plant residues in the soil (freshening of grassy meadows) in various agrotechnical schemes. The adjustable processing depth is approximately 8 to 18 cm.
Hinged Type
2. Working speed 8-12 km/h
3. The depth of tillage is 8-18 cm.
4. Height 1400 cm.
5. Transport speed, no more than 20 km/h.
6. Ground clearance, not less than 300 mm,
7. Transfer to transport and work.
positions Hydraulic, hydrofed by the tractor's hinged system

The harrow contains two rows of disks, each of which is located on an individual rack, which is attached to the bar with two L-shaped brackets (diameter 20 mm). This design excludes clogging of the interdisk space. The harrow can be used in all soil and climatic zones where the soil moisture does not exceed 27 percent and the soil hardness does not exceed 3.5 MPa, and it is also not recommended to use this harrow in areas with significant stony inclusions. Due to the use of individual racks in the design, the front harrow can be used at high working speeds - up to 14 km/h.

Discs are mounted on hubs that rotate around an axis on roller bearing units at an angle of attack of 21 degrees and a vertical inclination of 21 degrees.
(//tractor-service.com)
The fixing and adjusting nut of the hub bearing is closed by a flange with a cap, which performs two functions:
- hub sealing
- fastening of the working body (BDF disc) to the hub.

The rear rollers of the harrow provide two functions:
- crushed soil
- compacts and aligns the surface

The necessary depth of loosening and stable movement of the harrow-tractor unit is ensured by a lanyard (screw mechanism with right and left thread), which provides adjustment of the vertical position of the roller.

The harrow is aggregated with tractors equipped with a hydraulic system with a capacity of from 40 (for the BDF-1.8 mounted harrow) to 320 (for the BDFP-7.0 trailed harrow) horsepower, depending on the width of the implement.

The design of the roller attachment allows you to shift (move) the roller to the left or right (if necessary).
