Hoe BMR-6 m Rotary, Poltava region.

Rotary harrow BR-6 Rotary harrowHot harrow:
The way of aggregation by Vesnoy
Productivity per unit of basic time, not less, ha 10
Design width of capture, m 6.0
Driving speed, km/h - working -15-20 transport up to 20(//tractor-service.com)
Overall dimensions in working position, mm, length - 1430+26 width-6000+40 height-1450+11
Cultivator mass (construction), kg 1200+20
Features of the construction of working bodies:
A balancer on a standing hoe, provides soil copying.
Two-row closed ball bearings are installed in the hub of toothed discs, which significantly improves the operational qualities of the hoe:
- lubrication of hinges is not required, as the bearings are lubricated for the entire service life.
