Cultivator KRN-5, 6, inter-row for plow crops, Kharkiv region.

CultivatorKRN-5,6,interrow for row crops it is used for inter-row processing and feeding of high-stem plow crops sown with row spacings of 450-700 mm and more. The processing speed is up to 10 km/hour in all soil and climatic zones, excluding areas with stony soils.

According to the order of consumers, it can be supplied:

- with fat-seeding device for applying fertilizer

- with a transport device.

- with sections on bearings (203, 205, 503)

- withkushniks.

Technical characteristics:

In the transport position - semi-mounted.

In the working position - spring.

- Working width of capture 6.1m

- Working speed for basic operations up to 10 km/h.

- Transport speed up to 15 km/h

- The number of sections of working bodies is 9 pcs.(//tractor-service.com)

- Width between rows 700mm

- The number of rows processed by the cultivator in one pass 8

- The mass of the machine with a complete set of working bodies is 920 kg.

- Ground clearance not less than 300 mm.

- Overall dimensions

In working position

Width 6750mm

Length 2100mm

Height 1200mm

In transport position

Width 2100mm

Length 7680mm

Height 1500mm
