Grain seeder TITAN-Harvest 420 (mini-till) patented hit of 2017 Characteristics, Dnipropetrovsk region.

Grain seeder TITAN-Harvest 420 (mini-till) patented hit of 2017
Features
Harvest Brand
Type Seed drill
Gripping width, m 4.2
The number of rows, pcs. 28
Width between rows, cm 15
Sowing rates for seeds, kg/ha 0.5-400
Sowing rates for fertilized, kg/ha 25-200(//tractor-service.com)
The depth of planting seeds and fertilized, mm 40-80
Working speed, km/h 9-12
Productivity, ha/h 4-5
Total capacity of seed bunkers, l 960
Total capacity of bunkers for fertilizer, l 540
Overall dimensions, mm 5200x2400x2400
Mass, kg 3200
It is aggregated with tractors with a capacity of at least hp. 80
The seeder has two capacious hoppers - 950 l for seeds and 500 l for fertilizer, which creates prerequisites for high productivity.
The mechanism for raising and lowering the coulters is located behind the coulter, which allows you to achieve pressure forces on the coulter due to the spring mechanism from 80 to 130 kg. SZ-3.6, SZ-5.4, KRN-5.6, KRNV-5.6, SUPN-8, UPS-8. of activity
