Hydromotors MPG, Dnipropetrovsk region.

Hydromotors of the MHP series are produced under the license of the company "Danfoss" - Denmark, with volumes from 40 to 315 cm and various versions of connecting shafts.
Hydromotors of the MHP series are produced under the license of the Danfoss company - Denmark, with volumes from 40 to 315 cm and various versions of connecting shafts (cylindrical, slotted, conical according to special customer sizes). They are intended for the drive of working bodies of agricultural machinery, tractor machinery, road construction, municipal, woodworking machines, equipment and mechanisms working in fire-explosive media and conditions of high humidity.
Hydromotors of the MHP series are reversible hydraulic machines of the planetary type with non-adjustable parameters. The working body consists of a rotor, stator and rollers. The rotor and stator with rollers together with two plates form closed chambers of variable volume, into which, with the help of a spool device, a working fluid is supplied under pressure, which causes the output shaft to rotate through the cardan system. Working liquid: any mineral oil with a kinematic viscosity (20 - 800) x 10-6 m2 / sec. at a temperature of (243-363) 0K. Ambient temperature OM - 50°C to + 50°C.
To protect the cuff seal from the pressure of drainage leaks of the working fluid exceeding 1 MPa, it is necessary to provide a drainage hydraulic line connected to the drainage hole.
When the pressure in the main drain is up to 1 MPa, it is allowed to not install a drain line,drain drain will take place through one of the non-return valves into the drain cavity of the hydraulic motor. The check valve is activated by an excess pressure of 0.1 MPa in relation to the pressure of the drain cavity.
The hydraulic motor should not be subject to mechanical effects from the deformation and displacement of the hydraulic lines connected to it. It is prohibited to perform installation using blows on the hydraulic motor. ATTENTION: Disassembly of the hydraulic motor is prohibited. In case of disassembly, claims are not accepted.(//tractor-service.com)
The warranty period of the hydraulic motor is 24 months after shipment from the factory, but not more than 18 months from the day of commissioning and operation, not exceeding 3000 hours, which complies with TU 23.2.1588-82. Storage conditions for hydraulic motors (before commissioning) should be 1 (L) GOST 15150-69.
The MHP serves to transform the energy of the flow of working fluids, whichdevelops the pump, into the energy of rotation of the output shafts of machines and equipment, which activates their executive mechanism. The company "SDM-Hydravlyka" presents hydraulic planetary motors of the following manufacturers:
MHP-80, MHP-125, MHP-160, MHP-200, MHP-315
М+S Hydraulic Bulgaria Hydraulic Motor Type ММ, МР, MR, MH, MS, MT, MV
Sauer Danfoss Orbital Motors
Caproni Bulgaria Hydraulic Motor Type MGL, MHL
