Disk harrow semi-trailer AGN-2.5, AGN-3.3, AGN-4.2, AGM-4.2, AGN-6.3, Dnipropetrovsk region.

Disk semi-trailer harrow AGN-2.5, AGN-3.3, AGN-4.2, AGM-4.2, AGN-6.3
Semi-mounted disk harrow AGN-2.5
(unmaintained housing) Width of grip - 2.5 m. Production in 1 hour base. time - 2.0-2.5 ha/h Working speed - 7-10 km/h Number of working bodies - 14 pcs.
Disc diameter – 640+10 mm Weightplough – 1770+50 kg
Overall dimensions: length - 5500 mm
width – 2960 mm, height – 1565 mm

Semi-mounted disk harrow AGN-3.3
(unmaintained housing) Gripping width - 3.3 m. Production in 1 hour base. time - 2.6-3.3 ha/h Working speed - 7-10 km/h
The number of working bodies is 18 units.
Disc diameter – 640+10 mm Plow mass – 2050+60 kg
Overall dimensions: length - 5500 mm
width – 3550 mm, height – 1565 mm

Disc harrow semi-mounted AGN-4.2 (maintenance body) Working width - 4.2 m. Productivity in 1 hour of the main time - 3.0-4.2 ha/h(//tractor-service.com)
The working speed of movement is 8-10 km/h
Processing depth - 8-20 cm. Number of working bodies - 24 pcs. Disc diameter - 640 mm. Mass of the unit - 3500 kg.
Overall dimensions: length - 6000 mm, 158
ширина – 4300 мм, высота – 1710 мм

Semi-mounted disc harrow AGM-4.2 (non-maintained body)
Harvesting width - 4.2 m. Productivity in 1 hour of the main time - 3.4-4.2 ha/h
The working speed of movement is 8-10 km/h
Processing depth - 5-20 cm. Number of working bodies - 24 pcs. Disc diameter - 640 mm. Mass of the unit - 3270 kg.
Overall dimensions: length - 5000 mm, 165
ширина – 2800 мм, высота – 3000 мм

Semi-mounted disk harrow AGN-6.3
(unmaintained housing) Width of grip - 6.3 m. Productivity in 1 hour of the main time - 5.0-6.3 ha/h Working speed - 8-10 km/h Processing depth - 10-20 cm. Quantity of working bodies - 34 pcs. Disc diameter - 640+10 mm. The mass of the unit is 6000 kg
Overall dimensions: length - 6000 mm,
width - 3220 mm, height - 3850 mm
