Technical characteristics:
- the volume of the bunker is 830 liters,
- width of capture 4 m.,
- aggregated with a tractor from 80 to 100 hp,
- the possible width between the rows is 12/13.8/16.6 cm.,
- possible number of coulters 33/29/24 pcs.,
- working speed of 7-12 km/h.,
- transport width - 2.5 m.
- sowing rate from 5 to 400 kg./ha.,
Basic equipment:
(//tractor-service.com)
- a new dosing system with a "Vario" stepless gearbox and "Elite" sowing coils (a combination of sowing coils for sowing normal and small seeds);
- an easily accessible bunker;
- 2 trays for collecting seeds and fertilizers when checking the sowing rate, which simultaneously serve as covers for seeding devices, a handle for turning the support-drive wheel
wheel, which is needed when setting the sowing rate;
- working chassis on 2
tires;
- single disc RoTeC+ coulters made of high-strength boron steel with a diameter of 400 mm and a thickness of 4 mm;
- the possibility of turning off the augers of the seed hopper;
- 2 tractor track looseners on spring supports; 150
- оснащення для адаптації до вітчизняних тракторів – перехідні муфти для гідросистем російських тракторів (під різьбу до трактора M 20х1,5 або M 27х1,5);
- operating instructions and a logarithmic disc for setting sowing rates, - mechanical adjustment of the change in the pressure of the coulters on the soil;
- the supporting scraper of the Control coulter with a width of 10 or 25 mm. to choose from;
Change of planter configuration to order. The possible working width of the planter D9 is 2.5 m., 3 m., 4 m., 6 m.
