5-body mounted plow with front plows (PMU-5-35P), Plant "Polygon", Odesa region.

Plow modular universal 5-piecebody with front plows, one of the first
large plows, which have the ability to work both with ordinary ones and in combination with
crawler tractors and plow the field.

The frame is made of one-piece drawn square tube,
the margin of strength which is sufficient for plowing hard soils.
Plows are installed on the plow, which serve to cut the upper layer.
soil to a depth of up to 12 centimeters and drops it upside down to the bottom of the furrow.
The construction of the plow is equipped with shear bolts with a diameter of 20 mm. which provides
safe operation in the case of cases hitting an obstacle. Body parts
are made of high-strength steel grades that undergo a full thermal cycle.
processing, which ensures the extension of their shelf life. The plow can be made in
left version or with striped cases.

CHARACTERISTICS:
Working width: 2 m.
Cover width: 40 cm.
Type of case: semi-screw with corner opening / strip with corner opening.
Plowing depth: 18-30 cm.
Clearance under the frame: 80 cm.
The distance between the cases: 85 cm.
Plow weight: 1050 kg.
Tractor movement: across the field.
Suitable fortractors capacity: 150-230 hp.

ADVANTAGES:
1. Increased clearance under the frame and moving the case out from under the frame makes it possible
use a plow in fields littered with crop residues;(//tractor-service.com)
2. The use of a bent rectangular rack of the housing increases the distance between the housings;
3. The semi-screw casing ensures better formation rotation;
4. When working on very heavy soils, one housing can be fixed in a non-working position.
position;
5. Convenience of adjustments and maintenance;
6. If necessary, it is possible to order any part for maintenance or repair;
7. Delivery by various services: Nova Poshta, SAT, Delivery, or others to any address.
settlement of Ukraine.

ADDITIONAL OPTIONS:
1. Equipment with housings with a strip dump. The price of the plow in this version is 185
становить 184 956 грн;
2. To order, the manufacture of a plow with left-hand housings, which is more efficient
when plowing on slopes, preventing soil compaction.

Plows of the "Polygon" Plant are designed for plowing various soils forgrains and technical
cultures to a depth of up to 30 cm, not clogged with stones, slate, etc.
obstacles, with specific soil resistance up to 0.09 MPa (0.9 kgf/cm2).

A very good tool that will help you with plowing the soil.

You can get additional information on the website: https://poligon.in.ua/,
or by phone:​​​​​​​
+380 67 524 5255
+380 67 524 5256

The WARRANTY applies to all equipment of the plant, and to domestically produced equipment.
state COMPENSATION in the amount of 25% of the cost.
