T-16MG clutch shaft (СШ20.21.126-1А), Kharkiv region.

YOU CAN ORDER ANY SPARE PARTS FROM US

             Buy a new main clutch shaft T-16MG (СШ20.21.126-1А) Z=23, at a minimally low price with a maximum quality guarantee. It is used in self-propelled chassis (tractors) T-16, T-16M, T-16MG, SSh-25, SSh-2540 produced by the Kharkiv self-propelled chassis plant (Kharkov, Ukraine).

           The shaft of the main clutch СШ20.21.126-1А is located inside the socket of the main gear housing, to which the engine is bolted through the flywheel casing. Through the shaft of the main clutch СШ20.21.126-1A, the torque from the D-21A-1 diesel engine is transmitted to the primary shaft СШ20.37.065 of the gearbox of the self-propelled chassis СШ-2540 (T-16МГ, T-16М).
            The driven part of the clutch consists of the driven disc DSSH14.21.021-2 connected through the shaft СШ20.21.126-1А to the primary shaft of the gearbox. Since the driven disc is constantly clamped between the pressure disc DSSH14.21.022А and the flywheel, it and the main shaft of the clutch rotate together with the crankshaft of the engine. At the rear end of the shaft, a toothed coupling СШ20.21.135 is installed on two segment keys, which has a groove under the cuff. The axial movement of the clutch is held to the left by a spring ring B-28 through a washer DSSH14.21.143, and a rubber ring DSSH14.21.148А.

           Shaft СШ20.21.126-1А of the clutch clutch rotates on two ball bearings 1204 and 407. The front bearing 407 is installed in the bore of the cup of the bearing СШ20.21.129 and is prevented from axial displacement by a round expandable retaining ring 2В-35. Due to the fact that the outer ring of the bearing 407 is held in the cup, and the inner shaft of the SSh20.21.126-1A spring ring 2B35, the shaft of the SSh20.21.126-1A is fixed against axial movement. Bearing 1204 of the rear end of the shaft СШ20.21.126-1А is installed in the groove of the flywheel and is held by a washer clamped by the bolts of the flywheel fastening on the crankshaft.

           Shaft СШ20.21.126-1А is in permanent engagement with gears СШ20.37.103 of the primary shaft of the transmission of self-propelled chassis СШ-2540 (T-16MG, T-16) and together they form a bevel gear.

The original. Manufacturer's warranty and quality. High strength, reliability and wear resistance is due to modern production technologies and high-quality materials. Not artisanal production.
            We sellspare parts for tractors T-16(СШ-2540), T-25A, T-25F, T-40, YMZ, MTZ, DT-75, T-150, T-150K, T-156, KhTZ-17021, KhTZ-17221 and cars of the KamAZ, GAZ family, as well asagricultural machinery, a wide assortment is available, wholesale prices. All products comply with all necessary norms and standards.  (//tractor-service.com)

            We sell all over Ukraine. Fast delivery with the help of transport companies, to any city of Ukraine, on time and on the conditions of transport companies.

             Cash on delivery, cash on delivery. Transfer to a PrivatBank card. Cashless payment (with VAT). 100% refund. Discounts for regular customers.

Weight: 2,690 kg Material — steel 20KHNZA

SELLING ONLY QUALITY SPARE PARTS

              In order to buy a new shaft of the main clutch T-16MG (СШ20.21.126-1А) Z=23, manufactured by ХЗТСШ  Ukraine, fill out an application on the website or contact us in any convenient way for you.

   At the moment, the new T-16MG main clutch shaft (СШ20.21.126-1А) Z=23, produced by ХЗТСШ Ukraine, is available in our warehouse and available to order.
