Sprayer OP-3000 / 21m. (Mixer, hydraulic boom TANDEM (Ukraine), Kirovohrad region.

Sprayer OP-3000 / 21m. The hydraulic grip width is 18 m, the lifting height is from 0.5 to 1.5 m. The bar is made of high-quality steel, which gives a long service life. The pendulum mechanism allows you to adjust the bar in the horizontal plane relative to the field surface.

Technical characteristics:
Trailer type
Productivity 1:00 operating time ha / h 9-12
The working speed of movement on the main operations km / h 6-10
Working width of capture m 18-21
Pump (made in Italy) l / min -160
aggregation 1.4
Tank capacity L 2000-3000 ± 05
Use of working fluid l / ha 60-600
Working pressure in the pressure main.
bar 1 - 5
Transport speed, no more than km/h - 20(//tractor-service.com)
Road clearance (with horizontal placement of the bed), 165
Однако мм 500
Track width mm 1500 ± 50
Machine weight (structural) kg-1800-2250
The power to drive the working bodies at the RPM of 540 rpm
kW -6
Polyethylene tank with a volume of 2000-3000 liters.
It is aggregated with tractors of class 1,4.

Injector mixer with a ceramic tip, which is installed on the bottom of the container.
The track width can be adjusted from 1500 to 2000 mm.
Wheels with a diameter of 32 provide a clearance of 500 mm and allow working at high speed.

DELIVERY ALL OVER UKRAINE.
