Disk harrow mounted/trailed BDF(P)-2.1-2.4-2.8 Compensation-40%, Zaporizhzhia region.

GOS COMPENSATION 25-40% Вавесные-прицепныебороны BDF-BDFP Trailed Harrow BDFP is produced with a working width from 1.8 to 4.2 meters. It is equipped with plate cylindrical rollers with a diameter of 400 mm. The harrow is intended for continuous and pre-sowing soil processing of various mechanical composition for technical, grain and fodder crops and with grinding and embedding of plant residues in the soil (refreshing of soddy meadows) in various agrotechnical schemes. The adjustable processing depth is approximately from 8 to 18 cm.
Disk the working body, which is a cut-out spherical disc (chamois), with a diameter of 650 mm, installed on the hub. and 6 mm thick, with internal sharpening along the entire contour. Thanks to the special geometry of the tubular rack, it is installed at an optimal angle of attack to the line of traction and an angle to the vertical, which ensures high-quality crushing, crushing and turnover of the cut layer.
The harrow is produced as a mounted BDF (working width from 1.8 to 3.1 meters) and a trailed BDF (working width from 2.4 to 7.0 meters). In both cases, the harrow is equipped with plate-type cylindrical rollers with a diameter of O 400, and harrows with a hydraulic lifting mechanism of the wings (grip width of 5.5 meters and higher) are equipped with a set of rods that allow to install a set of two rollers with a diameter of O 400 and O 255 ​​mm. or from a three-row spring-tooth harrow and roller O255 mm.
The harrow contains two rows of disks, each of which is located on an individual rack, which is attached to the bar with two L-shaped brackets (diameter 20 mm). This design excludes clogging of the interdisk space. The harrow can be used in all soil and climatic zones where the soil moisture does not exceed 27 percent and the soil hardness does not exceed 3.5 MPa, and it is also not recommended to use this harrow in areas with significant stony inclusions. Due to the use of individual racks in the design, the front harrow can be used at high working speeds - up to 14 km/h.
Unlike similar harrows of other manufacturers, the design of this harrow uses camomile discs (cut-out spherical) with a diameter of 650 mm, a thickness of 6 mm, made of 65G steel. During manufacturing, the discs are thermally treated, which ensures a hardness of 38-46 HRC.(//tractor-service.com)
Disks are installed on hubs that rotate around an axis on roller bearing units at an angle of attack of 21 degrees and a vertical inclination of 21 degrees.
The metal anther, which is installed on the axis during assembly, covers the hub, forming a protective structure, which is supplemented by a sleeve with an oil seal inside and an anther outside. The unit is very well sealed from the outside environment due to this design.
The fixing and adjusting nut of the hub bearing is closed by a flange with a cap, which performs two functions: sealing the hub, securing the working body (BDF disc) to the hub.
The scraper is attached with two bolts with square headrests to a bracket with two grooves, which, in turn, is welded to the rack and when the harrow is working, it cleans the working organ (disc BDF camomile) from sticking soil, winding plants, clogging harvest residues, and also directs the flow of soil in the direction of the harrow and turns it.
