BPD-3200 trailed harrow for MTZ-892 tractor MTZ-100, Zaporizhzhia region.

A new high-quality trailed harrow is availableBPD 3200 560mm discs traileddisc two-row discBPD harrow-3.2×2 is ideal for quick, surface treatment of stubble with intensive mixing, works smoothly even with a large amount of straw. Processing corn fields with a large amount of straw and stubble. Trailed two-row disc harrow BPD-3.2×2 Diameter of working bodies 560 mm is intended for resource-saving pre-sowing and main tillage to a depth of 8 to 15 cm for grain, technical and fodder crops, weed destruction and grinding of crop residues after harvesting crops, rejuvenation of meadows and pastures, as well as grinding, leveling and compaction soil.
The trailed two-row disc harrow BPD-3.2×2 is ideal for fast, surface processing of stubble with intensive mixing, works smoothly even with a large amount of straw. Processing of corn fields with a large amount of straw and stubble.

They are intended for the following works:
Loosening of the upper soil layer;
Leveling of the field surface after plowing;
Destruction of weeds;
Planting of seeds and fertilized;
Cutting meadows and pastures before plowing;
Stubble peeling;

Compact sizes in transport position;
High quality painting of the product.

Technical characteristics
Productivity for 1 hour of the main time (ha/h) up to 3.84
Working speed (km/h) up to 12
Width of capture, m 3.2±0.12
Constructive mass of the machine, kg 1600
Processing depth, cm up to 15
Overall dimensions (in working position), mm(//tractor-service.com)
Length 5265±160
Width 3366±100
Height 1150±35
Disc diameter, mm 560
Number of working bodies, pcs. 24
skating rink 1
Angle of attack of discs, degrees. 0° — 30°
Distance, mm
between discs in a row 250
between rows of disks 950
Service life, years 18
Test results
Indicators of the quality of soil treatment BPD 3200
The ridge of the soil surface, no more (see) 3
Crumbling soil, not less (the size of lumps not more than 25 mm.) (%) 90
Grinding of harvest residues (%) 101
Plant and harvest residues (%) 101
Aggregability of 90 hp:
DT-75, MTZ 892.2

Delivery across Ukraine! Работаем без предоплаты!
