Trailed disk harrows BDP-3, 2, BDP-4, 0 с d diskov-560, Mykolaiv region.

В наличии прицепные disc BDP-3.2, BDP-4.0 with a disc diameter of 560 mm.
Trailed aggregates are used for pre-sowing soil treatment for sowing various crops, destruction of weeds and grinding of crop residues after harvesting of crops, as well as grinding, leveling and compaction of the soil.Disk harrow 3.2 m,Disk harrow 4.0m, BDP-3.2, BDP-4.0
The harrow has two rows of discs with a diameter of 560 mm, installed on separate racks with an adjustable angle of attack, as well as a rolling roller. Disks installed on individual racks allow the harrow to work in fields with a large amount of plant residues and weeds, excluding the winding of plant residues on the axis of the disk and clogging of the space between the disks, and also ensures high maintainability of the unit. The designBPD unit ensures a smooth adjustment of the angle of attack of each row of discs in the range from 0° to 30°, which allows you to optimally adjust the harrow for different types of soil. Each disc of 4000 BPD, 3200 BDP is installed on an individual stand, which ensures stable operation of the harrow in fields with a large amount of plant residues, excluding the clogging of the interdisc space.

Technical characteristics
Unit type 3200 BDP
Productivity for 1 hour of the main time (ha/h) up to 3.84
Working speed (km/h) up to 12
Width of capture, m 3.2±0.12
Constructive mass of the machine, kg 1600
Processing depth, cm up to 15
Overall dimensions (in working position), mm
Length 5265±160
Width 3366±100
Height 1150±35
Disc diameter, mm 560
Number of working bodies, pcs. 24
skating rink 1
Angle of attack of discs, degrees. 0° — 30°
Distance, mm between disks in a row 250(//tractor-service.com)
between rows of discs 950
Service life, years 18
DT-75, MTZ 892.2

Unit type 4000 BPD - trailed
Productivity, ha/time 5.6
Working speed, km/h 10-12
Transport speed, km/h 15-20
Gripping width, m 4.0
Processing depth, mm 100-140
Angle of attack of discs, degrees. 0...30
Number of rows, pcs. -2
Diameter of working bodies, mm 560
Mass, kg - 2100
Tractor power, not less, hp 150
Reliable designs of the bearing unit

Optimum Price.
Warranty and Delivery.
Call!
