Zh5-OSB cream separator, Kyiv region.

Separator-cream separator Zh5-OSB, prod. 1000 l/h
Purpose: designed to separate whole milk into cream and skimmed milk (return) and simultaneously clean them of contamination. The separator is used at dairy enterprises, as well as at milk receiving points.
Technical characteristics:
Productivity, l/h 1000
Drum rotation frequency, rpm 8000
Time for the drum to reach the operating speed of rotation, min 1-4
Regulation of volume ratioscream to skimmed milk from 1:4 to 1:12
Fat content of skimmed milk according to Herberg, % 0.04
Installed power, kW 0.55(//tractor-service.com)
Overall dimensions, mm 755x420x700
Mass, kg 77
features:
- open supply of whole milk and open removal of cream and skimmed milk
- manual sediment discharge
- The drive mechanism (horizontal shaft with friction-centrifugal clutch, vertical shaft, pulsator) is designed to transmit rotation to the working body of the separator - the drum.
- there are holes with plugs for filling and removing oil.
- for the gradual and smooth transfer of rotation from the electric motor to the drum, there is a friction-centrifugal clutch
- the frequency of rotation of the drum is controlled using a pulsator
