Polygonmach jaw crusher, Turkey, Kyiv

Cheek crusherscrushers Polygonmach are intended for processing the initial process of crushing any type of material from the softest limestone to the hardest granite.

Polygonmach jaw crushers are used as first stage crushers in our stationary and mobile crushing plants.
High flywheel speeds, angles of working plates, protective plates and rear blocks, high characteristics due to special geometry, reliability, durability and user-friendly installation mechanisms of our jaw crushers provide excellent operational advantages for users. All our jaw crushers are equipped with hydraulic setting mechanisms.
The hydraulic adjustment mechanism allows you to set the gap of the jaw in accordance with the required fraction size of the final product.

Features of Polygonmach jaw crushers: The reinforced base frame is immersed under arc welding, which allows to reduce heat loads. Oversized, heavy-duty spherical, self-aligning roller bearings. The pitmans of our jaw crushers are capable of withstanding the heaviest loads thanks to their forged material of chromium-nickel steel.
If necessary, Polygonmach jaw crushers are equipped with automatic lubrication systems. Large flywheels, which ensure the preservation of inertia, destroy even the hardest materials.
You can familiarize yourself with the technical characteristics, technical drawing, basic dimensions and type of transportation of our main jaw crushers.

TECHNICAL CHARACTERISTICS OF THE PRIMARY TYPE OF JAW CRUSHER:

MODEL CJC-60 Entrance size (mm) 610 x 380
Motor Power (kW) 30
Flywheel speed (rpm) 330
Weight (kg) 6000

MODEL CJC-90
Entrance size (mm) 900 x 650
Motor Power (kW) 75
Flywheel speed (rpm) 293
Weight (kg) 11,400(//tractor-service.com)

MODEL CJC-110
Size at the entrance (mm) 1.100 x 850
Motor Power (kW) 132
Flywheel speed (rpm) 228
Weight (kg) 33,000

MODEL CJC-130
Size at the entrance (mm) 1.300 x 1.000
Motor Power (kW) 160
Flywheel speed (rpm) 210
Weight (kg) 42,500

MODEL CJC-140
Size at the entrance (mm) 1.400 x 1.100
Motor Power (kW) 200
Flywheel speed (rpm) 228
Weight (kg) 52,500

The official representative of the manufacturer - the Turkish company Polygonmach offers high-quality equipment at minimal prices and convenient delivery conditions.
The official representative of the manufacturer offers minimum factory prices.
Delivery of equipment to any region or country. The manufacturer carries out chief installation and personnel training.
To receive a commercial offer, please send a request to our e-mail.
