Vibration screens Polygonmach Turkey, Kyiv

Vibrating screens Polygonmach is the most preferred screening equipment for sieving all types of materials due to its durable and simple design.
The modular structure allows users to change spare parts and perform maintenance easily.

Vibrating screens Polygonmach can be made in "top" or "center" versions. The material of the sieve can be made of steel or polyurethane according to the hardness level of the sifted material.

Main characteristics of Polygonmach VIBRATING SCREENS:
Configurations with one, two, three or four screens are available
Frame or flat support frames (stress relief)
Eccentric shaft with precision machining and forging from forged steel
Excellent bearing fit and shaft strength Maximum performance of bearings with proprietary grease oroil Bearings from SKF, FAG, Timken and NSK

The design of the fastening bolt ensures exceptional reliability
Replaceable bolted and welded, wear-resistant, steel lining and lining.

Technical parameters:
MODEL CVS 2050 UT
Top type
Screen size (mm) 2.000 x 5.000
Qty. levels 2-3
Motor power (kW) 18.5
Vibration speed (rpm) 925 - 1.100
Weight (kg) 16,000

MODEL CVS 2060 UT
Top type
Screen size (mm) 2.000 x 6.000
Qty. levels 2-3
Motor power (kW) 30
Vibration speed (rpm) 925 - 1.100
Weight (kg) 19,000

MODEL CVS 2460 UT Upper type
Screen size (mm) 2,400 x 6,000
Qty. levels 3-4
Motor power (kW) 30(//tractor-service.com)
Vibration speed (rpm) 925 - 1.100
Weight (kg) 22,000

MODEL CVS 1650 Medium type
Screen size (mm) 1,600 x 5,000
Qty. levels 2-3-4
Motor power (kW) 15
Vibration speed (rpm) 1.000
Weight (kg) 12,000

MODEL CVS 2050 Medium type
Screen size (mm) 2,000 x 5,000
Qty. levels 2-3
Motor power (kW) 22
Vibration speed (rpm) 1.000
Weight (kg) 15,000

MODEL CVS 2060 Medium type
Screen size (mm) 2,000 x 6,000
Qty. levels 2-3
Motor power (kW) 30
Vibration speed (rpm) 1.000
Weight (kg) 17,000

MODEL CVS 2460 Medium type
Screen size (mm) 2,400 x 6,000
Qty. levels 3-4
Motor power (kW) 30
Vibration speed (rpm) 1.000
Weight (kg) 19,000

The official representative of the manufacturer - the Turkish company Polygonmach offers high-quality equipment at minimal prices and convenient delivery conditions.
The official representative of the manufacturer offers minimum factory prices. Delivery of equipment to any region or country.
The manufacturer carries out chief installation and personnel training.
To receive a commercial offer, please send a request to our e-mail.
