Grain seeder Harvest 360, Zaporizhzhya region.

Grain seeder 3.6 equipped with reliable coulter lifting shafts. They have a special design, thanks to which the coulter is always in an even position and the shafts do not break. In addition, the shafts work without scrolling, which significantly complicates the entire work process.
Therefore, if you need fast and efficient work with a minimum of costs, then buying a grain seeder 3.6 will be the wisest decision.
Despite its usual purpose, SZ 3.6 has a number of design advantages that significantly increase the speed and quality of work, as well as the reliability and durability of all its mechanisms.
The main feature of the frame is a reinforced sprengel, which increases the reliability of the fasteners. The volume tank (1145 l) allows you to load a large amount of seed material at once. It is also adapted for mineral fertilizers. The versatility and large size of the tank lead to the minimization of the frequency of filling it with crops and fertilizer by an average of 50%, which means that it significantly saves time, reduces fuel consumption and labor costs. In addition, all the fastenings of the tank to the rest of the mechanism are significantly strengthened, which ensures its stability.
The seeder is equipped with a reinforced spring. The hydraulic cylinder of the coulter does not break the frame. The wringer mechanism and coulter spring are significantly strengthened. The opener itself has a modern design. It is equipped with an offset disc. To increase the efficiency of the work, the angle of attack on the release spring was also significantly increased.
The rolling segment has similarities with some models of American production. Reliable supportwheels, ten degrees of depth adjustment, half-disk made of metal - contribute to the improvement of the quality of work and a long service life of the product. All details are pre-painted. Assembly of the product is carried out exclusively after painting all elements.
The seeder is equipped with Bellota coulters.
Characteristics
Harvest brand
Type Grain seeder
Working width, m 3.6(//tractor-service.com)
The number of rows, pcs. 24
Width between rows, cm 15
Sowing rates for seeds, kg/ha 0.5-400
Sowing rates for fertilized, kg/ha 25-200
The depth of planting seeds and fertilized, mm 40-80
Working speed, km/h 9-12
Productivity, ha/h 3.2-4.3
Total capacity of seed bunkers, l 700
Total capacity of bunkers for fertilizer, l 450
Overall dimensions, mm 4500x3700x1650
Mass, kg 1450
It is aggregated with tractors with a capacity of at least hp. 65
