Mower tractor finger KTP -1, 5, Zaporizhzhya region.

Mower Ktp-1,5
Additional photos on the site oylenergomash.com.ua

Technical characteristics:
The name of the indicator Ed. change Norma
Weight of the structure (dry) kg 90±5
Construction width of capture m 1.5 -0.02
Productivity in 1 hour of the main time ha/h from 1.25 to 2.5
The working speed of movement on the main operations km/h from 6 to 8
Transport speed when the mower is raised and fixed for long-distance travel, no more than km/h 20
Minimum cutting height mm 50
Type of cutting device segment-finger(//tractor-service.com)
The type of drive of the knife is a crank-crank mechanism
Knife stroke mm 76
Maintenance staff 1 person mechanic

Purpose of the mower:
The KTP-1.5 finger grass mower is intended for mowing sown and natural grasses with the laying of the mowed mass in the spread.
It is used in all soil and climatic zones.
The mower is aggregated with tractors. 0.6 ts (made in China and "Belarus 132M") and is hung directly on the tractor attachmenttractor.
Description:
The barmower is equipped with the best device in terms of cut quality, inertial forces, power consumption for cutting and the total load on the blades of the segments, as well as operational reliability, is a cutting device with a riveted finger. This cutting device does not require daily adjustment of the gaps between clamps and segments. The segment is not wiped with a clamp. The high-quality cut of both upright and receding stems, as the process of cutting inclined stems is made easier, if the stems are cut with a knife with the sharpening edge of the blade at the bottom, that is, an inverted segment. At the same time, clogging of the cutting apparatus is reduced.
The entire list of manufactured products is indicated on the site oylenergomash.com.ua
Delivery to any region of Ukraine.
