BDM mounted / trailed harrow, Odesa region.

OOO "DiskAgro", Odessa, produces and sells:

Disk harrow modernized (BDMN 2.1, 2.5, 3.1, mounted, BDMP 2.1, 2.5, 3.1 trailed).

The harrow has all the advantages of the AG harrow.

Thanks to the placement of the bearing assembly inside the sphere of the disc, as well as the placement of the disc in front of the rack, the gapsbetween the discs are processed due to the separation and displacement of the ground by the disc of the second row into the groove formed by the disc of the first row.

In this way, the load on the bearing unit is reduced and its durability increases.
(//tractor-service.com)
This harrow is effective when processing weedy fields, as well as at high humidity.

The BDM harrow can work the soil to a depth of up to 15 cm, grinding the harvest residues and destroying weeds.

The main advantages of this harrow are lightness, durability and ease of repair.

The harrow is aggregated with tractors MTZ-80/82, MTZ-100/102, YUMZ-80/82.

Productivity in 1 hour 2.5 Ha.

Working speed 8-10 km/h.
