KPPO cultivator - with 4 tooth harrow and roller, Vinnytsia region.

KPPO-4 cultivator is equipped with a spring-tooth harrow and rollers. KPPO 4trailer cultivator. Buy cultivatorcontinuous processing KPPO-4
Width of capture 4.0 (m)
Maximum processing depth 12.0 (cm)(//tractor-service.com)
Working speed 13.0 (km/h)
Speed of movement (transport) 20.0 (km/h)
Power of the tractor 60 (hp) Adjustment of the depth of movement of the working bodies is achieved by turning the wheel bracket around the axis to the required angle by lengthening or shortening the screw tie-rods. One side of the lanyard is attached to the upper point of the cheek of the wheel mechanism, and the other side is attached to the bracket welded to the front beam of the frame. Shortening the lanyard leads to the lowering of the wheels and a decrease in the tread depth of the legs. The lengthening of the lanyard, on the contrary, leads to the deepening of the paws.
