Trailed sprayer OSSH 2000, 2500 l boom 18 m, Kiev region.

Trailed sprayer OSSH 2000, 2500 l boom 18 m

Trailed sprayers manufactured by PP "Agrotechnika" Glevakha, Kyiv region. (Ukraine)

Sprayers of the OSH series are produced with a tank capacity of 2000 and 2500 l and a boom width of 18 m.Wheels 9.5-32 or 9.5-42, with reinforced hubs, can be installed on the sprayer.
All sprayers are equipped with Italian equipment from Arag, Lechler, Imovilli pompe (control panel, nozzles, hoses, filters, pump). They are delivered in an assembled state complete with a cardan shaft 6*8.
Warranty for the sprayer and all equipment - 1 year.

Technical characteristics:
Productivity in 1 hour of prime time - 19.2 - 28.8 ha/year;
The capacity of the tank is 2000 l; 2500 l (Ukrainian production)
Working width of capture - 18 m ;
The flow rate of the working fluid is regulated within - 70 - 400 l/a
Working speed - 8 - 12 km/h ;
Pump supply - from 133 l/min for a 2000 l tank; from 163 l/min for a 2500 l tank;
Working pressure - 1.5 - 8.0 atm ;
The height of the location of the sprinklers from the surface of the earth is adjustable within - 0.5 - 1.5 m;
Ground clearance - 0.50 m (tyres 9.5 r 32); 0.75 m (tyres 9.5 r 42)
Nozzles on sprayers, single-position, Italian production with a blue sprayer ST 110-03
The bar is designed and produced by the Ukrainian manufacturer "Agrotechnika" (Glevakh village, Kyiv region)
The bar has effective (patented) mechanisms for stabilizing the position of the working bodies, fixing the sections of the bar in one plane and preventing its damage when it collides with obstacles, as well as mechanisms for smoothing dynamic loads in the vertical and horizontal planes.(//tractor-service.com)
The boom is raised and lowered from the tractor cab using a hydraulic system and two hydraulic cylinders, the lifting height is 1.5 m, the lowering is up to 0.5 m,
Manual assembly and disassembly using an improved (patented) self-fixing mechanism of the rod section in one plane.
The bar has easily replaceable plates in places of abrasion, which extends its service life.
The term of production of sprayers is up to 10 working days from the moment of preliminary payment of 10%
All sprayers can be equipped with additional equipment at the request of the client.
Bravo-180S computer (the main function is spill control regardless of speed):
Bravo-400S computer (section-by-section disconnection of booms, wrapped navigation system)
Mixer:
- tank 28 l – (Ukraine)
- tank 25 l –(Italy)
- tank 35 l – (Italy)
Promopore
Bar lighting
Foot dimensions.
A set of containers for flushing the system (the Italian container is already included)
Flushing the tank
Stainless pipes to replace PPR pipes (surcharge)
3-position nozzles with nozzles ST, IDK, KAS (made in Italy, nozzles by Lechler)
Nozzle 3-position POLSKA with nozzles ST, ST-С, KAS: (with 7 holes)
