Wide-grip aggregate KGSh-8 KGSh-4 solid trailed cultivator, Dnepropetrovsk region.

Wide-range aggregateКГШШ-8 КГШШ-4 слошнойtrailer cultivator.
Technical characteristics of the cultivator
Type of Machine Semi-trailer
Processing depth 5-15 cm.
The length in the working position is 8000 mm.
Height in working position 2300 mm.
Type of working organ flat-cut arrow paw(//tractor-service.com)
The minimum distance between adjacent working bodies on the frame is 230 mm.
The working width of the paw is 310 mm.
Overlap of paws 80 mm.
Standard equipment 3-row harrow with spring teeth
Optionally equipped plastic skating rink with a pitch of ~100 mm.
with a diameter of 255 mm.
The clearance under the frame (from the soles of the paws) is 700 mm.
The minimum distance between adjacent working bodies is 690 mm.
