Motoblok diesel DTZ 576D (3 forward 1-reverse) 7, 6 hp. Free Shipping, Rivne region.

NO PREPAYMENT
FREE HOME DELIVERY!

The DTZ-576D diesel motoblock has one significant difference from most motoblocks, it has a reduced speed, as in theWeima WM1100A-6 motoblock. The only difference is that the DTZ 576D can work at 3 forward speeds, while the Weima WM1100A-6 works at 4 forward speeds.

Thanks to the reduced speed, the DTZ-576D walk-behind tractor is perfectly adapted to planting and harvesting potatoes, since the machine does not get out of the hands of the operator. PTO, with the help of the power take-off shaft, you can use any attached equipment, rotary scythe, pump, etc.

Powerful diesel engine with a capacity of 7.6 hp. It was this engine that was installed on the Zirka 7.6 hp walk-behind tractor. The working volume of the motor is 310 cm3. The crankcase has a capacity of 1.1 liters. SAE10W40 engine oil is recommended. Forced air cooling. Air filter based on an oil bath. Such an air purification system is an order of magnitude more effective when performing work in a dusty environment, where for the most part agricultural machinery has to work.

This is a geared motoblock, which is characterized by a large weight, endurance and is much easier to control when performing cultivation. Gear housing, cast iron. The capacity of the gearbox is 2.7 l. Recommended oil TAD-17.

The width of the cultivation of this walk-behind tractor is regulated by set cutters from 620 mm to 1136 mm. Please note that in order to carry out weeding work, this model of walk-behind tractor has plant protection discs. The depth of cultivation is 150-300 mm. The depth of penetration of the cutter is regulated by the depth limiter, which is included in the kit.

Complete set.Pneumatic wheels. Set milling cutter. Plant protection discs. Depth limiter. Set of keys. Detailed instructions for use. Warranty card.

Technical characteristics:
Clearance, 420-650 mm
The number of cutters is 8 cutters. 32 knives
The size of the wheels is 4.00x10
Technical characteristics of the engine(//tractor-service.com)
Engine power 5.56 kW
Engine power 7.6 hp
The volume of oil in the engine crankcase. 1.1 l
Fuel tank volume, l 3.5 l

The working volume of the engine is 310 cm3
Air-forced cooling system
Engine type 4-stroke 1-cylinder
Start type Manual start
Fuel type Diesel
Engine speed 3600 rpm
Technical characteristics of the walk-behind tractor
There is a power take-off shaft. 1-PTO under key, diameter 18 mm.
The depth of cultivation is 150-300 mm.
Number of gears, forward/reverse 3 forward 1 reverse
Disc clutch type
Type of transmission Gear reducer
Cultivation width 622-874-1136 mm
Physical
Weight 120 kg
Overall dimensions 1740x1050x980 mm
