Cultivator KPSU-4 The powerful beam of the KPSU-4 frame is designed for large mechanical loads, Kherson region.

KPSU-4 cultivator The powerful beam of the KPSU-4 frame is designed for heavy mechanical loads. Reinforced steel brackets provide adjustment of working bodies in two planes.

The spring bar creates the vibration of the working bodies during tillage, which ensures good saturation of the upper layer with air and excludes the paw from breaking in the presence of an obstacle.

The mechanism for adjusting the depth of plowing provides an increased range of cultivation.

Self-aligningwheels provide good maneuverability when turning at the end of the race.

A hydraulic cylinder with a mechanism for adjusting the stroke of the rod is installed for raising and lowering the working bodies.

The reinforced beam of the frame is made of 75x75 mm corners, welded in pairs, the central bar, side bars, wheel mounting beams are made of N12 channel.

Suspensions for fastening harrows are equipped with adjustment bolts that provide adjustment of the depth of harrow teeth.

Cultivators are aggregated with MTZ and YuMZ type tractors.

To increase the working width, two cultivators connected by a KPC-14.000 hinge with a SP-1 hitch are aggregated with T-150 and DT-75 tractors.

K-701, T4A tractors are combined with four KSP-4 cultivators connected by three hinges with a SP-15A hitch.

Also, we sell spare parts for the cultivator.

MAIN TECHNICAL CHARACTERISTICS OF THE CULTIVATOR:

Cultivator productivity:(//tractor-service.com)

— of the main time, ha/hour Up to 4.8

— operational, ha/hour 2.6

Total width of capture, m 4

Working speed, km/h 10-12

Transport speed, km/h Up to 20

Depth of processing with arrow feet, mm 50-120

The depth of processing with tooth harrows with paws, mm 40-80

Soil loosening (size of fractions 1-25 mm), % 80%

Trimming weeds, % 100%

Dimensions and weight of the cultivator: 178

Габариты, мм 4050х4090х1010

Mass, kg 900

Direct deliveries!!! Delivery to other regions
