Осевые вентиляторы Deltafan 630/R/8-8/40/230, Киев

Axial fans 630/R/8-8/40/230 wall-mounted standard fans for mounting on the wall in any position. Fan frames are made of impact-resistant polystyrene HIPS (O 250-500) or amorphous plastic ABS (O 560-710), resistant to light and ultraviolet rays (color RAL 9017). Protective grille between the engine and the workingwheel. The working wheels of fans are made of cast polypropylene (PPG) and reinforced with fiberglass (blades) and cast aluminum (AL – hub of the working wheelwheels). Fan motors are asynchronous, single-phase 230V/50Hz or three-phase 400V/230V/50Hz. Single-phase motors are adapted to voltage regulation of the speed of rotation, and three-phase motors are adapted to regulation with the help of a frequency converter (inverter) and in the standard version thermal protection. Degree of protection of motors IP 44 (0.04 – 0.09 kW) or 66 (others), insulation of heat resistance class F. Maximum operating temperature 40oC (0.04 – 0.09 kW) or 60oC (others). Deltafan fans are supplied as standard in the exhaust version (A) - the direction of the air flow from the engine to the rotor. Version (B) is made to order - the supply version with the reverse direction of the air flow.

The rotation speed is 1350 rev/min.
Productivity 13500 m3/h
Power 0.75 kW
Current 4.7 A(//tractor-service.com)
IP 66
Max. Operating temperature 60 C
Weight 17 kg
SPL sound pressure 69 dB(A)
The power of acoustic LM is 80 dB(A)
Regulator type SPA-5
