Conveyor grooved folding, Poltava region.

We offer for production a sliding groove conveyor for heavy loads. Thanks to the sliding mechanism, the "pipe in the pipe" can be expanded to a height of 2 to 4 meters. This makes it possible to unload construction waste from the windows of construction objects to the street or lower floors, which in turn saves considerable money on the wages of loaders. It can also be used in other industries.

The length of the conveyor: 8000 mm along the axes of the drum;

Tape width: 500mm;

Conveyor type: Belt, grooved;

Conveyor frame type: Inclined;

Type of supports: Supports that are unscrewed when the conveyor is at work +wheels with a gazelle hub;

Drive type: shaft drive;

Type of surface for the tape: roller support (with a step of 500 mm), on three rollers, roller diameter 57 mm;(//tractor-service.com)

Tape type: 19000x500-4 TK100 2/0;

Conveyor material: structural steel with powder coating;

Bearing material: steel;

Loading height: 2000-4000mm (pipe-in-pipe adjustment), unloading height 500mm;

Tape speed: 0.5 m/s;

Motor: 1.5 kW;

Electrical connection: 380V;

The location of the control panel: on the conveyor.
