CTS biodiesel plant, 2-5 t/day (Semi-automatic), Raw material any vegetable oil, Kharkiv region.

CTS biodiesel plant, 2-5 t/day (Semi-automatic), Any raw materialvegetable oil.

High-class equipment from one of the best European manufacturers. Reliable, technological, at a reasonable price, much lower than competitors.

Equipment of the CTS company, 2-5 t/shift, for the production of biodiesel from any vegetable oil - sunflower, rapeseed, cotton, coconut, etc.

Unlike companies that produce equipment for the production of biodiesel based on old, "barrel" technologies used in the last century, our company uses the principle of high-frequency magnetic pulse cavitation, which was used in secret technologies, which allows us to achieve significant advantages:

Undemanding to the quality of the original oil.
High-frequency magnetic pulse cavitation reactors work successfully and stably on both crude and refined oil, as well as all types of animal fats and their mixtures with oil. These are sunflower, rapeseed, flax, palm, mustard, etc., with almost any acid number, as well as waste of over-fried oil from restaurants and bakeries, beef, pork and chicken fats - waste from livestock and poultry processing factories.

Completion of the reaction "in one pass"
Magnetic pulse cavitation technology does not require a repeated transesterification reaction, as in the old "barrel" technologies.
The time of obtaining finished biodiesel is reduced by 8-10 times.
Cleaning with sorbents, washing and drying of biodiesel is not required.
Minimum amount of alcohol and catalyst. Absence of recovery of alcohol.

During cavitation treatment, oil heating is not required, and as a result, electricity is saved by 5-7 times.

Low-temperature reaction at room temperature.
Magnetopulse high-frequency cavitation treatment of the reactor takes place at the molecular level. All components are exposed to pulses of magnetically directed cavitation.
The minimum dimensions of the modules are 5-10 times smaller than traditional complexes of similar performance.

Biodiesel from oil.

Installation BNR 500S (500 liters per hour) Semi-automatic

The BNR 500S automatic system consists of:

PPS-CT 1200: electronic system for preliminary dosing and processing of raw products.
Roton-B 15 - magnetic pulse reactor for BNR 500.(//tractor-service.com)
Automatic control system (electrical cabinet, PLC, PC, software, etc.)
Pipes, fittings, etc.
Division system:
6.1. Separation tank, sensors,pump, valves, etc.

7.2. Electronic monitoring system for bottling, separation and unloading of finished products

Technical characteristics:

Productivity, liter per hour 500

Nominal power, kW 16

Weight (approximately), kg 800

The degree of automation is semi-automatic

The operating mode is continuous.

Processing productivity, kWh/liter (no more) 0.028

Capacity adjustment - yes

The area occupied by one module is m2 3.0

Overall dimensions (L x W x H), mm 2250x1390x161

For the production of BioST, we cooperate only with reliable and well-known global suppliers, such as Grundfos, Siemens, Schneider Electric, Moeller, Fanuc, etc.

All BioST mechanisms are ATEX certified, which ensures safe operation of the unit with liquids such as methanol and catalyst.

BioST are designed for continuous operation for 24 hours and do not require special maintenance.
