Cultivator KPS-6 meters reinforced 4-row continuous processing, Kirovohrad region.

Cultivator KPS-6Cultivators of continuous processing with a working width of 4, 5, 6 meters, intended for resource-saving pre-sowing and steam soil cultivation, cutting and combing weeds, as well as leveling and compacting the soil surface for sowing.

It is used on all types of soil due to its versatility in the form of multiple adjustments of the cultivator itself and its attached equipment.

Processing width - 6 m.
Frame pipe 80 * 80 mm and 60 * 80 mm, thickness 6 mm
S-shaped spring stand "Bellota"(//tractor-service.com)
20 working bodies, paw 250 mm BOR steel with rear rake in 2 rows.
The thickness of the rake is 10 mm.
Rollers, adjustable in height with a screw and shock absorber.
The spring on the shock absorber is 10 mm. Bearing FKL.
Hydraulic cylinders 75 * 30 * 200
Widewheels 6.50 * 16
It is aggregated with tractors from 100 hp.
Weight 3000 kg
